For the latest parts pricing please use the Splash code in the search box in the top left hand corner.
Click here to access Service Manual
Item: |
Splash code: |
Part No: |
Description: |
|
1 |
Discontinued |
5100-7xx |
LABEL INSERT - BRUT |
|
1 |
Discontinued |
5300-7xx |
LABEL INSERT - MAGNUM |
|
1 |
450930 |
5700-7xx |
LABEL INSERT - OASIS |
|
1 |
Discontinued |
5900-7xx |
LABEL INSERT - BLIZZARD |
|
2 |
451042 |
7100-80 |
COVER-NEW 7000 STYLE |
| 2 |
Discontinued |
5100-8 |
COVER, BLACK (MAG & BRUT) |
|
2 |
450940 |
5700-8 |
COVER,GREY(OASIS&BLIZZARD) |
|
2 |
450882 |
5302-80 |
STD OCTI COVER |
|
3 |
450780 |
5100-6 |
DIAPHRAGM RETAINING RING |
|
4 |
450460 |
3108-13 |
DIAPHRAGM - BLUE |
|
5 |
451260 |
J12P04105SB |
SCREW(BRUT,MAGNUM,OASIS) |
|
5 |
180000 |
29-5900-J12 |
SCREW (BLIZZARD-TEFLON) |
|
6 |
450470 |
3108-3 |
LEVER(BRUT,MAGNUM,OASIS) |
|
6 |
450410 |
29-3108-3 |
LEVER (BLIZZARD) |
|
7 |
451100 |
9-5100-3 |
LEVER SUPPORT(BRUT,MAGNUM) |
|
7 |
451110 |
9-5100-3A |
LEVER SUPPORT(OASIS,BLIZZARD) |
|
8 |
450395 |
25-5700-21 |
HEAT TRANSFER FIN FLAT |
|
9 |
450396 |
25-5700-22 |
HEAT TRANSFER FIN DIMPLE |
|
10 |
451240 |
J113481874 |
SCREW FOR TRANSFER FIN |
|
11 |
450760 |
5100-29 |
SPRING |
|
12 |
450430 |
29-5700-1 |
STEM (NO SEAT INSERT) |
|
13 |
451120 |
978-9BN |
LP SEAT |
|
14 |
450640 |
3602-6A |
EXHAUST VALVE |
|
15A |
450960 |
5700-9 |
EXHAUST TEE - LONG |
|
15B |
450820 |
5100-9 |
EXHAUST TEE - SHORT |
|
16 |
450650 |
3702-5 |
SCREW |
|
17 |
390022 |
3602-3LS |
WISDOM MOUTHPIECE |
|
17 |
390021 |
3602-3 |
BRUT MOUTHPIECE |
|
18 |
450660 |
3786-9W |
CABLE TIE |
|
19 |
450770 |
5100-5A |
CASE |
|
19a |
450889 |
5602-1 |
CASE - NEW 7000 STYLE |
|
20 |
450260 |
1-5100-4 |
ORIFICE HOUSING (OASIS,MAG,BRUT) |
|
20 |
180000 |
1-5900-4 |
ORIFICE HOUSING (BLIZZARD) |
|
21 |
161499 |
G010A |
O-RING |
|
22 |
450730 |
41-4006-20A |
ADJUSTING ORIFICE |
|
23 |
161499 |
G010A |
O-RING |
|
24 |
130245 |
5016-20-33 |
LP HOSE |
|
25 |
390100 |
5100-27 |
HOSE PROTECTOR |
|
26 |
161500 |
G011B |
O-RING |
|
27 |
450900 |
5602-3 |
RETAINING CLIP |
|
28 |
451210 |
G106B |
O-RING |
|
29 |
451041 |
7100-2 |
COVER PLUG |
450680 |
4000-15 |
Service Kit |
|
450690 |
4000-15N |
Nitrox Service Kit |
Service manual
