Features
- Engineered with high flow characteristics to maximize regulator performance
- Valve design allows for easy and comfortable cylinder handling
- Slant back handwheel allows easy access
- Easy operation under all pressures
- Protective and attractive chrome plated finish
- Positive hand wheel grip for easy indentification of on/off direction
- 100% leak testing on entire production
- Designed with proven and readily available replacement valve parts
- Cycle tested 5000 times to exceed all real world applications
Specifications
- Gas Service: Breathing Air, Diving Applications
- Inlet Connection: 3/4 inch; Aluminum Cylinders NPSM
- Outlet Connection: CGA850 Yoke
- Safety Device: CG1, 3000PSI Service
- 3000PSI Service Pressure
- 5000PSI Rupture Disc
- Storage Temperature Min, Max: -55 C, 70 C
- Operating Temperature Min, Max: -45 C, 50 C
- Cycle Tested Minimum: 5000 Cycles, full pressure Nitrogen
- Overall Height: 3.875 inch
- Overall Length Installed Height: 2.875 inch
- Overall Weight: 1.3 lbs.
