SYNCHRO 2ND STAGE AND OCTO

For the latest parts pricing please use the Splash code in the search box in the top left hand corner.

Click here to access Service Manual

Item: Splash Code: Part No: Description:
1 180000 S500021 O-Ring
2 180000 S842031 Orifice
3 180000 S800003 O-Ring
4 180000 S842032 Hose Connection
5 180000 S77494 O-Ring
6 180000 S842033 Exhaust Tee
7 180000 S500023 Mouthpiece Tie
8 130313   Mouthpiece
9 180000 S842035 Exhaust Valve
10 180000 S842004 Case
11 180000 S842003 Diaphragm
13 180000 S842007 Internal Retaining Ring
14 180000 S842008 Antifriction Washer
15 180000 S842009G Front Cover - Grey
15a 180000 S842009Y Front Cover - Yellow
17 180000 S842011 Complete Retaining Ring
18 180000 S842013 Synchro Decal
19 180000 S540007 O-Ring
20 180000 S842020 Complete Jetavator
21 180000 S842021 Exhaust Tee Plug
22 180000 S842022 Seat
23 180000 S842023 Stem
24 180000 S842024 Spring
25 180000 S842025 Lever Support
26 180000 S842026 Insert Housing
27 180000 S842027 Lever
28 180000 S842028 Washer
29 180000 S500019 Stop Nut
30 180000 S842019 Cover Washer

162105
8422
Service Kit - 2nd Stage
